ISO & DIN 歐規標準伺服液壓缸 (含傳感器)

ISO / DIN 歐規標準液壓缸介紹 (含傳感器)

ISO 6022 / 6020-1 / 6020-2 / DIN 24333 標準定義了用於工業應用的液壓缸規範。這些液壓缸旨在確保在各種機械和設備中的可靠性、效率和兼容性。ISO 和 DIN 標準的液壓缸以其堅固的結構而著稱，能夠承受高壓並提供平穩的運行。

邦特液壓的製造能力

  • 標準：ISO 6020-1, ISO 6020-2, ISO 6022, DIN 24333
  • 6 種安裝樣式
  • 鑽孔直徑：40 至 320 毫米
  • 杆直徑：25 至 220 毫米
  • 行程長度可達 6 米

邦特自豪地提供 ISO 和 DIN 標準液壓缸的製造服務。憑藉我們先進的工程專業知識和最先進的製造設施，我們能夠生產符合 ISO 和 DIN 標準嚴格要求的高品質液壓缸。我們的液壓缸設計耐用且性能卓越，適用於建築、農業和製造等行業的各種應用。

我們專注於定制以滿足特定客戶需求，確保每個液壓缸都能無縫地融入現有系統。我們對質量和精度的承諾保證了我們製造的每個液壓缸均符合最高行業標準。

對於可靠和高效的液壓解決方案，邦特是您在 ISO 和 DIN 標準液壓缸生產方面值得信賴的夥伴。

如需更多詳情，請與我們聯繫或發送電子郵件！

詢問 線上目錄



Standards:

The installation dimensions of the cylinders and mounting styles meet the requirements of DIN 24333 and ISO 6022.

Clevis Mounted Cylinders

Cylinders with pivot mountings, which absorb forces on their centreline, should be used for applications where the machine member to be moved travels in a curved path. They may be used for tension (pull) or compression (push) applications. Fixed clevis mounting cylinders MP3 may be used if the curved path of the piston rod travel is in a single plane; for applications where the piston rod will travel in a path either side of the true plane of motion, the spherical bearing mounting MP5 is recommended.

Standards:

The installation dimensions of the cylinders and mounting styles meet the requirements of DIN 24333 and ISO 6022.

Trunnion Mounted Cylinders

These cylinders are designed to absorb force on their centre-lines. They are suitable for tension (pull) or compression (push) applications, and may be used where the machine member to be moved travels in a curved path, in a single plane. Trunnion pins are designed for shear loads only and should be subjected to minimum bending stresses.

Standards:

The installation dimensions of the cylinders and mounting styles meet the requirements of DIN 24333 and ISO 6022.

Foot Mounted Cylinders

MS2 cylinders do not absorb forces on their centreline. As a result, the application of force by the cylinder produces a turning moment which attempts to rotate the cylinder about its mounting bolts. It is important, therefore, that the cylinder should be firmly secured to the machine member on which it is mounted and that the load should be effectively guided, to avoid side loads being applied to the rod gland and piston bearings.
The MS2 foot mounted cylinder is not an ISO standard mounting.

Standards:

The installation dimensions of the cylinders and mounting styles meet the requirements of DIN 24333 and ISO 6022.

Head Mounted Cylinders

This mounting style is used for straight line force transfer applications in which the cylinder being pulled. The mounting flange surface should be flat, and the rod end should be piloted into it. The frame on which the cylinder is mounted must be sufficiently rigid to resist bending moments resulted from lateral force.
